HomeProductsDiscrete Semiconductor ProductsTransistors - FETs, MOSFETs - SingleIXFH150N30X3
IXYS
Image may be representation.
See specs for product details.
IXFH150N30X3IXYS MOSFET N-CH 300V 150A TO247
Part NumberIXFH150N30X3
PackageTO-247-3
ManufacturerIXYS / Littelfuse
RoHs Status
Manufacturer Part NumberIXYS-IXFH150N30X3
DescriptionMOSFET N-CH 300V 150A TO247
In stock1556
Data sheet
IXFH150N30X3.pdf
Please click " QUICK RFQ " and provide your contact information,
or email us at [email protected].
We will respond promptly to your inquiry.
In stock: 1556 pcs Required fields are indicated by an asterisk ( * )

Please send RFQ, we will respond immediately.

  • Specifications
  • Product Details - IXFH150N30X3
  • IXFH150N30X3 Tech Specifications
    IXYS - IXFH150N30X3 technical specifications, attributes, parameters and parts with similar specifications to IXYS - IXFH150N30X3
    Manufacturer IXYS / Littelfuse
    Vgs(th) (Max) @ Id 4.5V @ 4mA
    Vgs (Max) ±20V
    Technology MOSFET (Metal Oxide)
    Supplier Device Package TO-247 (IXTH)
    Series HiPerFET™, Ultra X3
    Rds On (Max) @ Id, Vgs 8.3mOhm @ 75A, 10V
    Power Dissipation (Max) 890W (Tc)
    Package / Case TO-247-3
    Package Tube
    Operating Temperature -55°C ~ 150°C (TJ)
    Mounting Type Through Hole
    Input Capacitance (Ciss) (Max) @ Vds 13100 pF @ 25 V
    Gate Charge (Qg) (Max) @ Vgs 177 nC @ 10 V
    FET Type N-Channel
    FET Feature -
    Drive Voltage (Max Rds On, Min Rds On) 10V
    Drain to Source Voltage (Vdss) 300 V
    Current - Continuous Drain (Id) @ 25°C 150A (Tc)
    Base Product Number IXFH150
  • TheIXFH150N30X3is a Discrete Semiconductor Products component, full developed and mass-produced by IXYS manufacturer, subject to rigorous quality control and successfully meeting production standards. The product description is MOSFET N-CH 300V 150A TO247 and it falls under the category of Transistors - FETs, MOSFETs - Single, with Manufacturer of IXYS / Littelfuse and Vgs(th) (Max) @ Id of 4.5V @ 4mA and Vgs (Max) of ±20V. Efficient purchasing through Ixys-Electronics.com. Here, you can find a wide variety of electronic components produced by manufacturers worldwide. If you do not find the information you are looking for, you can obtain more valuable information via email [email protected], such as stock quantities, special pricing, datasheets, and more details for IXFH150N30X3 or order. We are always pleased to hear from you, so feel free to contact us at any time.

Product Comparison

Product Attribute IXFH150N30X3 IXFH150N25X3HV IXFH15N100 IXFH14N60P3
Part Number IXFH150N30X3 IXFH150N25X3HV IXFH15N100 IXFH14N60P3
Manufacturer IXYS IXYS IXYS IXYS
Package / Case TO-247-3 - TO-247-3 TO-247-3
Operating Temperature -55°C ~ 150°C (TJ) - -55°C ~ 150°C (TJ) -55°C ~ 150°C (TJ)
Drive Voltage (Max Rds On, Min Rds On) 10V - 10V 10V
Base Product Number IXFH150 IXFH150 IXFH15 IXFH14
Mounting Type Through Hole - Through Hole Through Hole
Drain to Source Voltage (Vdss) 300 V - 1000 V 600 V
Vgs (Max) ±20V ±20V ±20V ±30V
Supplier Device Package TO-247 (IXTH) - TO-247AD (IXFH) TO-247AD (IXFH)
Input Capacitance (Ciss) (Max) @ Vds 13100 pF @ 25 V - 4500 pF @ 25 V 1480 pF @ 25 V
Rds On (Max) @ Id, Vgs 8.3mOhm @ 75A, 10V - 700mOhm @ 500mA, 10V 540mOhm @ 7A, 10V
FET Type N-Channel - N-Channel N-Channel
Power Dissipation (Max) 890W (Tc) - 360W (Tc) 327W (Tc)
Gate Charge (Qg) (Max) @ Vgs 177 nC @ 10 V - 220 nC @ 10 V 25 nC @ 10 V
Technology MOSFET (Metal Oxide) - MOSFET (Metal Oxide) MOSFET (Metal Oxide)
FET Feature - - - -
Package Tube Tube Tube Tube
Current - Continuous Drain (Id) @ 25°C 150A (Tc) - 15A (Tc) 14A (Tc)
Series HiPerFET™, Ultra X3 HiPerFET™, Ultra X3 HiPerFET™ HiPerFET™, Polar3™
Vgs(th) (Max) @ Id 4.5V @ 4mA - 4.5V @ 4mA 5V @ 1mA
